PRBSN221- PREPARATION BOOTH – FLOOR SUCTION
The DaTo PRBSN221 Floor Suction Preparation Booth is designed to provide a clean, controlled, and dust-free environment for vehicle surface preparation before painting. Its advanced ventilation and filtration system ensures efficient dust extraction from the floor level, maintaining high hygiene standards and improving overall paint quality. The booth is engineered for flexible installation in modern service centers and body shops.
It is widely used as brake service equipment in the UAE, supporting workshop operations with brake repair machines in Dubai systems. Ideal for automotive workshop tools in the UAE, it enhances brake maintenance equipment in Dubai and provides efficient vehicle brake tools in the UAE.
Specifications
| Category | Specification |
| Model | PRBSN221 |
| Internal Size (L×B×H) | 6300 × 3450 × 2800 mm |
| External Size (L×B×H) | 7800 × 3450 × 3350 mm |
| Loading Capacity | 650 kg/wheel |
| Surface Area | 9 m² |
| Metal Basement | No |
| Drive-in Ramps | No |
| Ceiling Lighting | 6 units, 4×36W |
| Brightness | 500 Lux |
| Pre Filters | Fiber glass, Paint-Stop Filters |
| Ceiling Filters | 6 units EU5 Fine Filters |
| Floor Filters | Fiber glass, Paint-Stop Filters |
| Motor | 1 × 7.5 kW, 970 RPM, 380V, 50Hz |
| Fan Capacity | 25,000 m³/h |
SKU
PRBSN221
Category PREPARATION BOOTH
